ANPING FUHUA WIRE MESH MAKING CO.,LTD
| Tipo di pagamento: | L/C,T/T,D/P |
| Incoterm: | FOB,CFR,CIF,EXW |
| Quantità di ordine minimo: | 1 Roll |
| Trasporti: | Ocean,Land,Air |
| Porta: | TIANJIN |
Modello n.: TYPE1
Wire Gauge: 2.0,3.0,1.8mm
Width: 0.5-4m
Length: 5-25m
Transport Package: Weaving Bag
Origin: China
Codice SA: 7314410000
Material: Galvanized Iron Wire
Aplikasi: Fence Mesh, Protecting Mesh, Construction Wire Mesh
Hole Shape: Diamond
Weave Technique: Twill Weave
Trattamento della superficie: Galvanized
Mesh: 60*60mm,50*50mm ,
| Unità vendibili | : | Roll |
The file is encrypted. Please fill in the following information to continue accessing it
| Opening | 1" | 1.5" | 2" | 2.25" | 2.4" | 2.5" | 3" | 4" |
| 25mm | 40mm | 50mm | 55mm | 60mm | 65mm | 76mm | 100mm | |
| Wire diameter | BWG18-BWG13 | BWG16-BWG8 | BWG14-BWG7 | |||||
| 1.2mm-2.4mm | 1.6mm-4.2mm | 1.0mm-4.5mm | ||||||
| Length of the roll | 1.0m-50m | |||||||
| Width of the roll | 0.5m-5.0m | |||||||
| Materials and specifications can be made according to customers specific requirements | ||||||||
| Fence Height | Fence Length(2m) | Fence Length(2.5m) | ||||||
| cm | Wire Gauge | Wire Diameter | Opening | Weight kg/piece | Fixing Pole | Opening cm | Weight kg/piece | Fixing Pole |
| mm | cm | Weight kg/set | Weight kg/set | |||||
| 60 | 10#/8# | 3.2 4 | 5X12 | 6.5 | 1.9 | 5X12 | 8.6 | 1.9 |
| 80 | 10#/8# | 3.2 4 | 5X12 | 7.5 | 2.3 | 5X12 | 9.9 | 2.3 |
| 100 | 10#/8# | 3.2 4 | 5X12 | 8.5 | 2.7 | 5X12 | 11.2 | 2.7 |
| 120 | 10#/8# | 3.2 4 | 5X12 | 9 | 3.1 | 5X12 | 11.9 | 3.1 |
| 150 | 10#/8# | 3.2 4 | 5X12 | 11 | 3.7 | 5X12 | 14.5 | 3.7 |
| 180 | 10#/8# | 3.2 4 | 5X12 | 12.5 | 4.3 | 5X12 | 16.5 | 4.3 |
| 200 | 10#/8# | 3.2 4 | 5X12 | 13.5 | 4.7 | 5X12 | 17.8 | 4.7 |
