Fornitura di maglie a filo quadrato
Fornitura di maglie a filo quadrato
Fornitura di maglie a filo quadrato
Fornitura di maglie a filo quadrato
Fornitura di maglie a filo quadrato

Fornitura di maglie a filo quadrato

Ottieni l'ultimo prezzo
Tipo di pagamento:L/C,T/T,D/P
Incoterm:FOB,CFR,CIF,EXW
Quantità di ordine minimo:1 Piece/Pieces
Trasporti:Ocean,Land,Air
Caratteristiche del prodotto

MaterialeFilo in lega di alluminio

SpecieTela metallica

Processo ProduttivoIntrecciata

Luogo D'origineCina

Material TypeStainless Steel Wire

Weave TechniquePlain Weave

Wire Mesh Width1m

TechniqueWoven

Nickels8%

Transport PackageCarton, Water Proof Paper

SpecificationExport Standard

TrademarkRUILI

OriginAnping

Capacità di produzione10000 Square Meters / Week

SertifikasiIso9001

MaterialSus316

750mm*2000mm1500mm*3000mm

Hole ShapeSquare

AplikasiFilter, Construction Wire Mesh

TypeStainless Steel Plain Wire Mesh

Confezionamento e consegna
Unità vendibili : Piece/Pieces

The file is encrypted. Please fill in the following information to continue accessing it

Descrizione del prodotto





L'acciaio inossidabile è selezionato per le loro caratteristiche resistenti all'usura, resistenti al calore, resistenti all'acido e alla corrosione. Molti gradi diversi di inossidabile sono usati in un panno. T304 è il più comune, ma gli altri sono utilizzati in applicazioni specifiche per sfruttare le proprietà uniche di ogni grado. La rete metallica in acciaio inossidabile è ampiamente utilizzata nell'industria mineraria, chimica, nell'industria alimentare e nell'industria farmaceutica.
Materiali a filo: SUS302, 304, 316, 304L, 316L.
Caratteristiche: apertura quadrata, meno rigida rispetto alla trama semplice, in particolare adatto alla deformazione, una stoffa a filo forte a causa del rapporto di diametro e apertura del filo, è utilizzato principalmente per la filtrazione inferiore a 63 μm.
Modelli di tessitura tipici: trama semplice, tessitura in twill, tessitura olandese.
Uso generale: maglia in filo in acciaio inossidabile, con la sua eccellente resistenza contro acido, alcali, calore e corrosione, trovano ampi usi nella lavorazione di oli, sostanze chimiche, alimenti, prodotti farmaceutici, anche ordinamento e screening di solido, liquido e gas nella mia Spazio aereo, produzione di macchine, ecc.

Stainless Steel Wire Mesh and Wire Cloth, Plain Weave
Mesh Wire Dia. (MM) Opening (MM) Material (AISI)
7meshx7mesh 1.00 2.63 304 or316
10meshx10mesh 0.60 1.94 304 or316
12meshx12mesh 0.50 1.62 304 or316
16meshx16mesh 0.40 1.19 304 or316
16meshx16mesh 0.35 1.24 304 or316
18meshx18mesh 0.35 1.06 304 or316
20meshx20mesh 0.40 0.87 304 or316
24meshx24mesh 0.26 0.80 304 or316
30meshx30mesh 0.30 0.55 304 or316
35meshx35mesh 0.17 0.56 304 or316
40meshx40mesh 0.23 0.40 304 or316
50meshx50mesh 0.20 0.31 304 or316
60meshx60mesh 0.15 0.27 304 or316
70meshx70mesh 0.12 0.24 304 or316
80meshx80mesh 0.13 0.19 304 or316
90meshx90mesh 0.12 0.16 304 or316
100meshx100mesh 0.10 0.15 304 or316
120meshx120mesh 0.09 0.12 304 or316
150meshx150mesh 0.063 0.11 304 or316
180meshx180mesh 0.053 0.09 304 or316
200meshx200mesh 0.053 0.07 304 or316

Stainless Steel Wire Mesh and Wire Cloth, Twill Weave
Mesh Wire Dia. (MM) Opening (MM) Material (AISI)
250meshx250mesh 0.040 0.063 316
300meshx300mesh 0.040 0.044 316
325meshx325mesh 0.035 0.043 316L
350meshx350mesh 0.030 0.042 316L
400meshx400mesh 0.030 0.033 316L
450meshx450mesh 0.028 0.028 316L
500meshx500mesh 0.025 0.026 316L

Stainless Steel Wire Cloth, Dutch Weave
Mesh Wire Dia. (MM) Material (AISI)
12mesh x 64mesh 0.58 x 0.40 304 or 316
24mesh x 110mesh 0.36 x 0.25 304 or 316
14mesh x 88mesh 0.50 x 0.33 304 or 316
30mesh x 150mesh 0.23 x 0.18 304 or 316
40mesh x 200mesh 0.18 x 0.13 304 or 316
50mesh x 250mesh 0.14 x 0.11 304 or 316
80mesh x 700mesh 0.10 x 0.08 304 or 316
165mesh x 800mesh 0.071 x 0.040 304 or 316
165mesh x 1400mesh 0.06 x 0.04 304 or 316
200mesh x 1800mesh 0.05 x 0.032 304 or 316
825mesh x 2300mesh 0.035 x 0.025 316L
400mesh x 2800mesh 0.030 x 0.02 316L

Larghezza della rete in filo in acciaio inossidabile: 0,6 m-1,5 m
